QSFP-100G-ZR4-S optical transceiveris compatible QSFP28 optical transceiver module is designed for 100GBASE Ethernet throughput up to 80km via single-mode fiber (SMF) using 1310nm viļņa garums via duplex LC connector. BOX+FPC+PCBA independent design, good reliability, good air tightness, good heat dissipation performance. The transceiver complies with IEEE 802.3ba 100GBASE-LR4 and IEEE 802.3bm CAUI{-4 standarti. The digital diagnostic function is also available via the I2C interface, specified by the QSFP28 MSA, allow access to real-time operational parameters. With these features, this easy-install, hot-swappable transceiver is appropriateable for a variety of applications such as 100G Ethernet, telecommunications, and data centers.
|
SPE |
QSFP28 100G 1295-1310nm 80KM LC DDM |
|
PN |
QSFP28-ZR4 |
|
Forma Koeficients |
QSFP28 |
|
Max Data Rate |
103.125Gbps (4x 25.78Gbps) |
|
Viļņu garumu |
1295-1310nm |
|
Max kabelis attālums |
80km |
|
Savienotājs |
Duplekss LC |
|
Media |
SMF |
|
Raidītājs tips |
EML |
|
TX Jauda |
2% 7e6.5dBm |
|
Uztvērējs jutība |
<-28dBm |
|
Jauda patēriņš |
Mazāk nekā vai vienāds līdz 6W |
|
Temperatūra |
0 to 70 grāds (32 līdz 158 grāds F) |
|
DDM/DOM |
|
|
Bits Kļūda Attiecība (BER) |
5E-5 |
|
|
QSFP28 MSA |
|
Pulkstenis un dati atkopšana |
TX & RX Iebūvēts CDR |
|
Modulācija formāts |
NRZ |
|
Garantijas |
3 Years |
